Device’s principle

This is the system for eliminating the particulate material in the dust collection gas with droplet, liquid film bubble and others by dispersing cleansing solution or that removes by carrying out dissolution or chemical reaction by having the gaseous contaminant pass through gas, liquid contact surface, to disperse at the inside of the liquid (adsorbent). Cleaning dust collection can effectively process dust and gas contaminant together. Thus, this is a device that is used widely for polluted gas treatment. In particular, particle treatment is carried out by attaching grain dust to the droplet, liquid film and bubble and others that are generated by dispersing cleansing solution to coagulate and to collect. Cleaning dust collection device wet scrubber, ventury scrubber, eject ventury scrubber, cyclone spray scrubber, packing tower etc

Characteristics

  • - Removal of dust and gas that result in high temperature is easy.
  • - Possible to select absorption solution according to the type of exhaust gas.
  • - Able to remove DUST and MIST GAS.
  • - Process of toxic exhaust gas is easy.
Usage
Plating plant’s smelting furnace, Incinerator and refining plant, Surface treatment plant,
Exhaust polluted gas adherence removal

Wet scrubber

WET SCRUBBER
Model No. Specifications
(M)
Pump & Motor
(kw)
총진재량
(㎡)
Fan & Motor
(HP)
Amount of spray
(ℓ/min)
Nozzle수량
(EA)
Demister Specifications
(Ø10)개
CHS-S50 Ø1.03 0.5 0.67 3 100 8 Ø1.03
CHS-S100 Ø1.46 1 1.34 7.5 200 16 Ø1.46
CHS-S150 Ø1.78 1.5 1.99 10 300 24 Ø1.78
CHS-S200 Ø2.06 2 2.06 15 400 32 Ø2.06
CHS-S250 Ø2.3 2.5 3.3 20 500 40 Ø2.3
CHS-S300 Ø2.52 3 4 25 600 48 Ø2.52
CHS-S400 Ø2.91 4 5.3 30 800 56 Ø2.91
CHS-S500 Ø3.26 5 6.7 40 1000 64 Ø3.26
CHS-S600 Ø3.57 6 8 50 1200 72 Ø3.57
CHS-S700 Ø3.86 7 9.3 60 1400 80 Ø3.86

※ FAN’s power was factored in as merely the main body’s pressure loss.
