Device's principle
This is the device that removes grain dust with the force of inertia, blocking ability, diffusion force, gravity after having dirty gas pass through the follicle side. Dust collection effect is high, and it is effective for fine particle removal as well. Safe continuous operation is enabled and treatment air volume for each unit area mass is large. Thus, installation space is small. It is possible to install even when the dirt concentration is large. Diverse methods including the inflow of the filtering and gas for treatment to the filter cloth can be selected depending on the type of gas for treatment. Dust on the filtering material’s surface is detached with the back-draught, vibration and impact ejection method.
Characteristics
- - Dust collection function is superb, and pressure loss is small.
- - Not many malfunctions and long follicle lifetime.
- - Fluctuation of pressure loss is small.
- - Simple structure, and ease of maintenance and management.
Usage
Metal smelting, refining, heat treatment, nonmetallic mineral, Material and wood treatment, other polishing,
discarding and others
discarding and others
Filter dust collector
| Model No. | 여과면적 (㎡) |
여포수량 (EA) |
전자변수량 (EA) |
표준필요 공기량 (ℓ/min) |
적용 Compressor (kw) |
집진기 Size (m/m) | Bag크기 경 X 장(m/m) |
|
|---|---|---|---|---|---|---|---|---|
| 크기 | 높이 | |||||||
| CHS-BF100 | 87.7 | 64(8 X 8) | 8 | 210 | 2.2 | 1950W X 1950L | 4950 | 165Ø X 2650L |
| CHS-BF200 | 164.4 | 120(8 X 12) | 12 | 425 | 5.5 | 1950W X 2890L | 4150 | 상동 |
| CHS-BF300 | 252.1 | 184(8 X 23) | 23 | 650 | 7.5 | 1950W X 5480L | 4080 | 상동 |
| CHS-BF400 | 339.8 | 248(8 X 31) | 31 | 880 | 7.5 | 1950W X 7360L | 4080 | 상동 |
| CHS-BF500 | 416.5 | 304(16 X 19) | 38 | 1080 | 11 | 3850W X 4560L | 5960 | 상동 |
| CHS-BF600 | 504.2 | 368(16 X 23) | 46 | 1310 | 11 | 3850W X 5480L | 5960 | 상동 |
| CHS-BF700 | 591.8 | 432(16 X 27) | 54 | 1530 | 15 | 3850W X 6420L | 5960 | 상동 |
| CHS-BF800 | 679.5 | 496(16 X 31) | 62 | 1760 | 15 | 3850W X 7360L | 5960 | 상동 |
※ The above shown chart was calculated with the standard of 1.2m/min for the filtering speed when it comes to the filtering area mass, and can change depending on the type of dust and field conditions.
