Device’s principle
MIST is spread out widely with ㎕ that is less than decimal point since dissipation action following gas flow results at the same time when liquid film is separated during the processes such as absorption, distillation, extraction in the environment or chemical process device. WIRE DEMIST –OR and CHEVRON MIST ELIMINATOR are suitable since they use the inertial impaction of the particle that factored in the energy loss, efficiency, and economic viability when it comes to the separation and collection method.
Characteristics
- - Collection effect is superb even amidst the fast fluid velocity as well.
- - Suitable for high-viscosity fluid.
- - Small clogging due to contaminant.
- - Easy to maintain it clean.
- - Pressure loss is small.
- - Relatively low cost and semi-permanent lifetime.
- - Able to select diverse materials according to operating conditions.
Usage
Chemical process, machine tool, metal treatment plant, for oil recovery
Mist collector
| Model No. | Flowe Velocity (m/sec) |
Baffle수량 (EA) |
Baffle크기 (m/m) |
집진기 Size (m/m) | 입준, 준구경 (D) |
Motor용량 (HP) |
|
|---|---|---|---|---|---|---|---|
| 크기 | 높이 | ||||||
| CHS-OMC100 | 3.2m/sec | 23EA | 720W X 720H | 1820W X 2100L | 1800H | Ø460 X 520 | 2HP |
| CHS-OMC200 | 상동 | 32EA | 1020W X 1020H | 1120W X 2350L | 2120H | Ø650 X 730 | 5HP |
| CHS-OMC300 | 상동 | 39EA | 1250W X 1250H | 1350W X 2500L | 2400H | Ø800 X 890 | 7.5HP |
| CHS-OMC400 | 상동 | 45EA | 1450W X 1450H | 1550W X 2700L | 2600H | Ø920 X 1030 | 10HP |
| CHS-OMC500 | 상동 | 51EA | 1620W X 1620H | 1720W X 2850L | 2800H | Ø1030 X 1150 | 10HP |
| CHS-OMC600 | 상동 | 56EA | 1770W X 1770H | 1870W X 3000L | 2900H | Ø1130 X 1260 | 15HP |
※ Motor power was calculated using only the main body’s pressure loss was used as the standard. (50mmAq standard)
